Name: ISO 9239-1 ASTM E 846 Flooring Radiant Heat Flux Test Apparatus Tester Machine
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YYF008
Price: 25,000.00 USD
Availability: InStock

Zu Hause > produits > Entflammbarkeits-Testgerät >

ISO 9239-1 ASTM E 846 Flooring Radiant Heat Flux Test Apparatus Tester Machine

ISO 9239-1 flooring radiant heat tester

ASTM E 846 flammability test machine

radiant heat flux test apparatus

Herkunftsort:

Guangdong, China

Markenname:

YUYANG

Zertifizierung:

Modellnummer:

YYF008

Kontakt mit uns

Fordern Sie ein Zitat

ISO 9239-1 ASTM E 846 Flooring Radiant Heat Flux Test Apparatus Tester Machine

Einzelheiten zum Produkt

Wärmeflussbereich:

0-15 kW/m2

Genauigkeit des Wärmeflusses:

± 0,2 kW/m2

Abgasgeschwindigkeit:

2,5 ± 0,2 m/s

Flammenhöhe:

60–120 mm verstellbar

Zündsystem:

Hochspannungselektronik

Gasflussrate:

0,026 ± 0,002 L/S

Gesamtleistung:

2KW

Stromversorgung:

AC 220V, 50 Hz

Strahlungsenergiefluss:

1,1-10,9 kW/m2

Bereich der Wärmestrommessgeräte:

0-50 kW/m2

Oberflächenemissivität:

ε=0,95±0,05

Betriebsspannung:

230 V, 10 A

Betriebstemperatur:

10°C bis 35°C

Winkel der Strahlungsplatte:

30º

Gasversorgung:

mit einer Leistung von mehr als 1000 W

Hervorheben:

ISO 9239-1 flooring radiant heat tester

ASTM E 846 flammability test machine

radiant heat flux test apparatus

Zahlungs- und Versandbedingungen

Min Bestellmenge

Verwandte Produkte

BS 476 Teil 7 Aufbaustoff Oberflächen-Flammenverbreitungsprüfgerät Elektronik

Beste Preis

16 CFR Part 1611 SPI Flammability Testing Equipment Electronic Fire Testing Machine

Beste Preis

ISO 834 BS 476 Teil 20&22 Baumaterialien und Bauwerke

Beste Preis

Kegelkalorimeter Wärmefreisetzungsrate Entzündbarkeitsprüfungsausrüstung Elektronische Maschinentester

Beste Preis

Kontakt mit uns

+86-13825722581

jackson.sun@yuyangtest.com

86-769-26622869

Kontaktieren Sie uns jetzt

Beschreibung des Produkts

ISO 9239-1 ASTM E 846 Flooring Radiant Heat Flux Test Apparatus

This professional testing machine measures the critical radiant flux and flame spread characteristics of flooring materials according to international fire safety standards.

Product Overview

The ISO 9239 Radiant Flooring Panel test is the cornerstone of flooring materials reaction to fire tests in the Euroclass system. The apparatus measures flame spread of samples under thermal exposure using a radiant heat ignition source, simulating fire conditions that radiate onto flooring in adjacent rooms or corridors.

This flooring radiant panel test apparatus is also compliant with ASTM E648 and DIN 4102 Part 14 standards.

Compliance Standards

• GB/T 11785 - Flooring combustion performance measurement with radiant heat source
• ISO 9239-1:2002 - Flooring combustion performance determined with radiant heat resource
• ASTM E648 - Critical radiant flux of floor-covering systems using radiant heat
• ASTM E970 - Critical radiant flux of exposed attic floor insulation using radiant heat energy
• NFPA 253 - Critical radiant flux of floor covering systems using radiant heat energy

Key Features

Insulated test chamber with calcium silicate insulation board and temperature-resistant observation window
Stainless steel sample support assembly on sliding platform for safe and easy sample loading
Gas-fuelled radiant panel inclined at 30° directed at horizontally mounted floor covering specimens
Radiant energy flux distribution from 10.9 kW/m² to 1.1 kW/m²
Dummy calibration specimen with holder and calibrated heat flux meter
Measures distance burned until flame-out, converted to equivalent critical radiant flux in kW/m²
Heat flux meter range: 0-50 kW/m² with surface emissivity ε=0.95±0.05
Integrated smoke measuring system according to DIN 50055
Control rack for convenient observation and operation during setup and calibration
Automatic ignition of radiant panel with safety cut-out
Automatic moving T-type ignition burner
Stainless steel hood with smoke measurement ports

Installation Requirements

Parameter	Specification
Electrical	230 volts Nominal, 10 Amps
Ambient Temperature	Operating range: 10°C to 35°C
Gas Supplies	Propane and air compressor
